No-Lead Bronze Spring Check Valve - 1" Female Pipe Thread x 1" Female Pipe Thread

The Merrill 850 Series CVANL Check Valve is constructed from no-lead bronze and engineered for long-lasting performance in water well systems. Its no-spin poppet and corrosion-resistant design ensure smooth, quiet, and reliable operation. Suitable for both vertical and horizontal installations, this valve provides a strong seal and exceptional durability, even in demanding environments. The check valve has a Delrin guide bearing for the poppet stem which assures smooth noise-free and long-life valve operation.

• 1" Female Iron Pipe x 1" Female Iron Pipe (FIP)
• connection type: FPT x FPT
• material: no-lead bronze
• inlet: 1 inch
• outlet: 1 inch
• Mfg. PN: CVANL100
• NO LEAD - can be used for drinking water
• IAPMO, NSF 61, NSF 372 certified
• No spin poppet
• 500lb of tension (down pull)
• Valve body and poppet are cast with no lead bronze
• Abrasion-resistant o-ring is precision fitted to the poppet for easy seal
• tapered self-cleaning valve seat
• corrosion-resistant - stainless steel spring and stainless steel lock nut
• can be used in both vertical and horizontal positions
• Used for:
  • water wells
  • irrigation
  • jet pump and submersible systems
  • water pump systems
